Gomelong is a professional manufactures of Three Phase LCD Digital Kwh Meter with CT. Our professional expertise in manufacturing Three Phase LCD Digital Kwh Meter with CT has been honed over the past 10+ years. Three Phase LCD Digital Kwh Meter with CT is a kind of new style three phase four wire multifunction energy meter.Three Phase LCD Digital Kwh Meter with CT completely accord with relevant technical requirements of class 1 three phase active energy meter stipulated in international standard IEC 62053-21 and class1 three phase reactive energy meter in international standard IEC 62053-23. Three phase digital voltage bidirectional meters can accurately and directly measure 50Hz or 60Hz active energy consumption from three phase four wire AC electricity net.
Qucik Details of DTSD5558 Three Phase LCD Digital Kwh Meter with CT
Three Phase LCD Digital Kwh Meter with CT(Model DTSD5558 three phase four wire electronic multifunction energy meter ) is a kind of new style three phase four wire multifunction energy meter.Three Phase LCD Digital Kwh Meter with CT completely accord with relevant technical requirements of class 1 three phase active energy meter stipulated in international standard IEC 62053-21 and class1 three phase reactive energy meter in international standard IEC 62053-23. Three Phase LCD Digital Kwh Meter with CT can accurately and directly measure 50Hz or 60Hz active energy consumption from three phase four wire AC electricity net, Three Phase LCD Digital Kwh Meter with CT has LCD monitors shows the active energy power consumption, and there are far infrared and RS485 communication module in it. Three Phase LCD Digital Kwh Meter with CT has following features: good reliability, small volume, light weight, specious nice appearance, convenient installation, etc.
Features of DTSD5558 Three Phase LCD Digital Kwh Meter with CT
♦ Measurement of Import/Export active energy, current energy balance, Instant voltage/current/power
♦ PLC, Rs485, Infrared interface
♦ Event record: Cover open detection, Reverse current, Fraud
Technical Parameters of DTSD5558 Three Phase LCD Digital Kwh Meter with CT
|
Specification |
DTS5558L |
DTS5558 |
|
|
Accuracy |
Active |
Class1.0 |
Class1.0 |
|
Reactive |
Optional |
Optional |
|
|
Voltage |
Rated |
3x57.7/100V,3x220/380V 3x230/400V,3x240/415V |
3x57.7/100V,3x220/380V 3x230/400V,3x240/415V |
|
Range |
0.9Un~1.1Un |
0.9Un~1.1Un |
|
|
Limit |
0.8Un~1.2Un |
0.8Un~1.2Un |
|
|
Frequency |
|
50/60Hz |
50/60Hz |
|
Current |
Range |
1.5(6), 5(30), 10(50), 15(90), 20(100), 5(40), 5(100)A |
3x1.5(6), 3x 5(30), 3x 10(50), 3x 15(90), 3x 20(100), 3x 5(40), 3x 5(100)A |
|
Starting Current |
|
0.4%Ib |
0.4%Ib |
|
Constant |
Active |
1600imp/kWh |
1600imp/kWh |
|
Reactive |
\ |
\ |
|
|
Display |
Type |
LCD |
Register |
|
Digit |
6+1 |
6+1 |
|
|
Power Consumption |
Voltage Circuit |
≤0.8W,10VA |
≤0.8W,10VA |
|
Current Circuit |
≤4VA |
≤4VA |
|
|
Communication |
Interface |
Optical/Infrared/RS485 (Optional) |
Optical/Infrared/RS485 (Optional) |
|
Protocol |
MODBUS,DLT/645,IEC1107 |
MODBUS,DLT/645,IEC1107 |
|
|
Temperature |
Working Temperature |
-45℃~+55℃ |
-45℃~+55℃ |
|
Storage Temperature |
-40℃~+70℃ |
-40℃~+70℃ |
|
|
Humidity |
|
≤90% |
≤90% |
|
Protection |
|
IP54 |
IP54 |
